Controllers:

Keyboard: 37 Keys (mini-keyboard, transmits velocity)
4-way Joystick (with switch)
16 Pads (can transmit velocity or fixed value)
8 Rotary Encoders
8 Sliders
Value Dial

Display:

Main Display: 8 characters (8x5 dot) with 3 segment backlit LCD
Sub Display: 8 characters (8x5 dot) with 3 segment backlit LCD
Tempo LED

User Memory:

12 (preloaded from factory)

Connectors:

DC 9 V (AC adapter)
MIDI IN, OUT, THRU
USB connector
Footswitch Pedal

Power Supply:

USB Bus Powered, or
DC 9 V (AC adapter), or
(6) AA batteries

Power Consumption:

AC adapter: 3.5W (Max)

Dimensions:

20.63" (W) x 9.13"(D) x 2.76"(H)
524(W) x 232(D) x 70(H)mm

Weight:

2.6kg/5.73 lbs.

Accessories:

AC adapter (DC 9 V, 600mA),
USB Cable,
CD-ROM: microKONTROL Librarian Software, Template Sheet, Driver,
Name Sheet,
Seal for Trigger Pad

Options:

DS-1H Damper Pedal
PS-1 Pedal Switch

System Compatibility:

Macintosh:

Supported OS: Mac OS X v10.2 or later.
Supported Computer: Apple Macintosh with Mac OS X and USB port

Note: USB MIDI has been tested and works under Rosetta and Universal Binary on Intel-based Macs, using the standard Class Compliant driver. In this case, however, Port Names will be shown as generic names like Port 1, Port A etc. instead of the product name.

The Version 2.0 Editor Librarian is available for Windows XP and Mac OS X. Click here for additional information.

Mac Users: USB MIDI has been tested and works under Rosetta and Universal Binary on Intel-based Macs, using the standard Class Compliant driver. In this case, however, Port Names will be shown as generic names like Port 1, Port A etc. instead of the product name. The Editor has been tested on Intel-based Macs, and while not Universal Binary compliant, runs fine under Rosetta.

Windows:

Supported OS: Microsoft Windows XP Home Edition/Professional
Supported Computer: PC with Windows XP and USB port (recommended Intel USB chipset)
