EIA output power
(1 kHz, THD 1%) |
High: 50 W
Low: 250 W |
|
Distorsion |
<0.02% |
|
Input sensitivity |
+4dB dB (nominal) / -40dB (maximum) |
|
Input impedance |
20 kOhms (balanced) |
|
Components |
High: 1" driver with EWT horn and titanium
diaphragm
Low: 15" neodymium woofer |
|
Crossover frequency |
2.5 kHz @ 24 dB/ott. |
|
Frequency response |
48 - 20kHz (-10 dB) |
|
Max SPL continuous |
123 dB |
|
Dispersion (OxV) |
60° x 40° |
|
Connections |
1 x combo + 1 x XLR-M in parallel |
|
Controls |
Volume - shield - preset selector - line/mic
selector |
|
Power supply |
see label |
|
Construction |
High-density polypropylene - 2 aluminum
handles - 4 M10 flying points |
Dimensions
(W x H x D) |
475 x 810 x 430 mm |
|
Weight |
21 kg |
